Performance Tweaks
Do you want to make the very best use of your computer's RAM? There are
thousands of websites offering performance tweaks for XP and you could spend the
next week or more researching the ones you might like to perform, or you can
save yourself a lot of bother and read this article. There are hundreds of XP
tweaks, but you only need the handful listed here to obtain a significant
performance boost. The rest of the tweaks you might find will only give you
minor and often indiscernible performance benefits. If you don't have 512MB
of RAM or more, there are tweaks here that you can apply anyway, but the best
performance boost you'll ever get will be obtained by increasing your RAM.
Tweak #1: Graphical User Interface and Themes
Tweak #2: Enable ClearType
Tweak #3: Disable Last Access Timestamp
 |
Whenever XP reads a file, it stamps the file with the date
and time of the access. This feature has its
place but is not required for normal use unless you rely
on the date of last access for backup purposes, which is a rare
requirement for most backups. Putting a timestamp a file that has
just been read means that a write access has to be made to disk, so
every time a read is executed, a corresponding write is also
executed.
At the command prompt, enter the following then reboot;
FSUTIL behavior set disablelastaccess 1
Those of us who read and write English need to take note of
the American spelling of the BEHAVIOR parameter.
To turn timestamps back on, repeat the command but replace the 1
with 0. |
 |
 | |
Tweak #4: Kernel Paging and Cache Tuning
 |
256MB RAM is the absolute minimum to take advantage of the
changes in this tweak; however to get the best performance you need
512MB or more. Those with faster Pentium 4's should see a
significant performance boost from the combination of this tweak
plus tweaks 5 and 6. |
|
|
| |
- You should not perform any registry edits
unless you know what you are doing.
- If you apply this tweak, you should also apply
Tweaks #5 & #6.
|
|
|
| |
The "DisablePagingExecutive" entry in the registry prevents the
kernel (the core of the XP OS) from being rolled out to a page file
on disk. The effect of this part of the tweak is to cause
the OS to cache the Kernel and its entourage to RAM instead of to
disk, which makes XP far more responsive. |
|
|
| |
The "LargeSystemCache" registry entry forces XP to allocate all
but 4MB of system memory, that is system memory, not available
RAM, to the file system cache. The remaining 4MB of system memory is
used for disk caching, though XP will allocate more memory if it is
needed. |
|
|
| |
A modern hard disk will transfer sequential data to and from
disk at up to 40MB per second, or even faster on some of the more
expensive drives, but the LargeSystemCache tweak means
that effective transfer speeds of 1GB per second or more
can be obtained, depending on the amount of RAM in your system and
its operating speed. This is achieved because the LargeSystemCache
modification causes the OS to store data in RAM after it is read
from disk. It means that the OS is always using the optimum amount
of RAM instead of leaving it untouched for future use that may or
may not occur. Without this part of the tweak, 200MB or more of RAM
in a typical 512MB machine goes completely unused. |
 |
 |
| |
Some I/O intensive applications may take a hit in performance
from changing the LargeSystemCache, so this particular
component of the tweak should not be applied to a system
that is running either SQL Server or Internet Information Server
(IIS) because both of those applications perform their own
caching. |
|
|
| |
Start regedit and navigate to the following key: |
|
|
| |
[HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\
Control\Session Manager\Memory Management] |
|
|
| |
Add these two lines then save the changes and reboot: |
|
|
| |
"DisablePagingExecutive"=dword:00000001 |
|
|
| |
"LargeSystemCache"=dword:00000001 |
|
|
| |
To see the effects of this part of the tweak, launch a large,
memory hungry application. Any of the Microsoft Office suite of
applications will do that job nicely. Let the application load then
exit from it. Fasten your safety harness then launch the application
again. |
|
|
| |
A PC with a striped RAID 0 array of two ATA100 7,200 RPM disks
with a SiSoft Sandra Drive Index of 28,000 had the
two registry changes above applied to it and the
Drive Index tripled to an upper mark of 85,000. A similar but
scaled down performance increase can be expected for ATA 33/66
disks. |
 |
 | |
Tweak #5: Separate Window Processes
 |
This tweak provides significantly faster performance
and affords greater application stability. This part of the tweak
causes multiple instances of the same application to
execute in their own process and memory space. Of course, the
cost for improved performance and stability is memory since the
application and its attendant DLLs are loaded separately for each
instance.
If you have 512MB of RAM or more, this part of the
tweak is highly recommended because if, say Internet
Exploder, crashes then other Internet Exploder instances will
remain unaffected. |
|
|
| |
- Start Windows Explorer
- Select Tools
- Select Folder Options then select the
View tab
- Check the Launch folder windows in
separate process box and Apply
|
 |
 | |
Tweak #6: Processor Scheduling
 |
This tweak is impossible to explain without getting into the
technical ins and outs of binary values, bit pairs and bit
masks. Suffice it to say, it forces short, variable length processor
timeslices to be allocated to foreground processes three times more
often than those timeslices given to background
processes. |
|
|
| |
Start regedit and navigate to the following key: |
|
|
| |
[HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\ Control
\PriorityControl] |
|
|
| |
Change the dword value of Win32PrioritySeparation, save the
changes and reboot; |
|
|
| |
"Win32PrioritySeparation"=dword:00000026 |
|
|
| |
- The Win32PrioritySeparation value of 26 is hexadecimal, which
is 38 decimal.
|
|
|
| |
As with the cache tuning tweak (#5), this particular tweak should
not be applied to a system that is running either SQL Server or
Internet Information Server (IIS) unless you are certain that
you want to slow down those background processes. |
|
|
| |
For more information on how this tweak uses binary
values and bit pairs, read any of these articles
on Google. |
 |
 | |
Tweak #7: Turn Off the Indexing Service
 |
The Windows Search Companion has been very much maligned by the
technical community, and with good reason. It is, in my opinion, a
classic example of software that both uses resources and operates at
speeds that are inversely proportional to the function that it
performs and the value it provides. It is slow, ineffectual and
tantamount to useless for serious searching because it deliberately
ignores certain files and directories without allowing the user to
decide what should and should not be searched. In short, the Search
Companion is dysfunctional bloatware. |
|
|
| |
From a Microsoft Knowledgebase article
titled Windows XP may run slowly and you may see multiple symptoms
in Windows Task Manager:
This issue can occur if the Indexing service is
running on the computer. The Indexing service uses the Cidaemon.exe
process to index files. The Cidaemon.exe process builds and updates
the Index catalog. Additionally, the Cidaemon.exe process typically
uses lots of pagefile space and lots of CPU time.
The phrase, "typically uses lots of pagefile space and lots of
CPU time" looks like a Microsoft marketing droid's spin on the plain
English meaning of, "This is
bloatware."
http://support.microsoft.com/kb/899869/en-us |
|
|
| |
Whilst the Windows Search Companion will still function without
the indexing service, some performance benefits can be obtained by
utilising the indexing service. However the indexing service builds
a SQL database of keywords it finds in files. This means that to get
at the information compiled by the indexing service, the Search
Companion sends an SQL query to the database, which then returns the
information to the Search Companion. This can be a frustratingly
slow process, even on very fast machines. |
 |
 |
| |
Besides the feature and performance issues with Search Companion,
the indexing service works in the background, scouring almost every
file that it finds. On a new system, the indexing service can take
days to settle down. This is because the service puts a low priority
on its work. Despite this low priority, the indexing service can
cause serious performance degradation, especially in lower-end
machines because the computer's hard disk runs continuously. If you
have Office XP, you may find this Microsoft Office KB article of interest. |
|
|
| |
A much better searching alternative is to turn off the indexing
service and use Agent Ransack by
David Vest. |
|
|
| |
From the Agent Ransack website: "Agent Ransack is a free tool for
finding files and information on your hard drive fast and
efficiently. When searching the contents of files Agent Ransack
displays the text found so you can quickly browse the results
without having to separately open each file! Agent Ransack provides
compelling advantages over similar search tools: Regular expressions
that allow complex rule based searches. Immediate contents results
view. Various wizards to walk the user through the searching
process. Agent Ransack is provided free of charge for the benefit of
the Windows community. If you find it useful please register it,
free of charge." |
|
|
| |
To disable the indexing service: |
|
|
| |
- Click Start, Run, type services.msc then
press enter or click OK
- Scroll to the "Indexing Service" in the
right-hand pane and double-click it
- Change the Startup type to Manual or
Disable and Apply
- Click the Stop button and wait for the service to stop then
click OK
|
 |
 | |
